14.5 GHz Double Forward Coupling 0.4dB Rf Directional Coupler

Brand Name : Sinoscite

Model Number : CP13.75-14.5GW-2722

Certification : ISO 9001:2015

Place of Origin : Sichuan, China

MOQ : 1 Piece

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 2000 Piece per month

Delivery Time : Less than 4weeks

Packaging Details : Standard exporting carton , each product individually wrapped, high density foam protection professional packing.

Product Type : Coupler

Model : CP13.75-14.5GW-2722

Working Frequency : 13.75-14.5GHz

Insertion loss : ≤0.4dB

Coupling : 45dB±1dB

Coupling consistency : ≤±0.2dB

Directionality : ≥15dB

Main line VSWR : ≤1.3

Subline VSWR : ≤1.5

Main line interface : BJ120

Subline interface : SMA-K

Operating temperature : -40℃~+70℃

Material : Aluminum alloy

Exterior color : Navy White

Remarks : Double forward coupling, one reverse coupling, isolation connected to load
